Turbo Air TB13-8H-SWSSS-N Glass 3 Swing Door Back Bar

Turbo Air TB13-8H-SWSSS-N 3 Glass Swing Door Back Bar Fridge

The Turbo Air TB13-8H-SWSSS-N is a commercial back bar refrigerator featuring three full-length glass swing doors, a stainless steel exterior with stainless steel trim, and a back-mounted refrigeration system with no castors or legs for a flush, low-profile installation behind the bar. With a 246-litre capacity and 1352 mm width, it is well suited to high-volume venues that need reliable cold drink storage right at the point of service.

Powered by an eco-friendly R-290 hydrocarbon refrigerant with zero ozone depletion potential and an ultra-low global warming potential, the unit meets modern environmental standards without compromising performance. A forced-air cooling system, high-density CFC-free polyurethane insulation, and LED interior lighting with automatic fan shut-off when doors are open combine to deliver fast temperature recovery, even cabinet cooling, and genuine energy efficiency during busy service periods.

Key Benefits

• Keeps drinks at consistent serving temperature right at the point of dispense, reducing wait times and improving bar efficiency.
• Forced-air cooling system delivers fast temperature recovery after frequent door openings during peak service.
• R-290 hydrocarbon refrigerant is ozone-safe and has a global warming potential of just 3, supporting sustainable venue operations.
• Digital external temperature display allows staff to monitor cabinet conditions at a glance without opening the doors.
• Automatic fan shut-off when doors are open prevents warm air ingress, helping maintain interior temperature during busy periods.
• Energy-efficient LED lighting illuminates the full interior, making product selection faster and reducing electricity consumption.
• Self-closing, easy-grip doors reduce staff fatigue and help maintain temperature compliance during continuous service.
• Door locks included as standard, providing added product security after hours or in multi-staff environments.
• Back-mounted, no-castors, no-legs design sits flush and low-profile behind the bar, maximising usable counter space above.

Key Features

• Three full-length glass swing doors for clear product visibility and easy access.
• Stainless steel exterior cabinet with stainless steel door trim for durability and easy cleaning.
• Back-mounted refrigeration system; no castors or legs for a fixed, flush installation.
• R-290 hydrocarbon refrigerant with ODP of 0 and GWP of 3, compliant with EPA SNAP Program approval.
• Forced-air cooling system for rapid cooling and balanced temperature distribution throughout the cabinet.
• High-density, CFC-free polyurethane foam-in-place insulation in the cabinet structure and doors.
• External digital temperature control and monitoring display for easy, at-a-glance temperature management.
• LED interior lighting that illuminates every corner of the cabinet.
• Fan control function automatically shuts the evaporator fan off when a door is opened, preventing warm air from being drawn in.
• Adjustable, heavy-duty polyethylene (PE) coated wire shelves.
• Self-closing doors with ergonomic easy-grip handles.
• Door locks included as standard on all three doors.
• Anti-corrosion coated evaporator for extended service life.
• Hot gas condensate system with corrosion-resistant treated surfaces to prevent condensate overflow and refrigerant leakage.
• Self-contained refrigeration system for straightforward installation.
• 246-litre total capacity.

Specifications

• Width (mm): 1352
• Depth (mm): 550
• Height (mm): 800
• Capacity (Litres): 246L
• Refrigerant: R290
