Thermaster ZCDTD210 Supermarket Combined Freezer

Thermaster ZCDTD210 Supermarket Combined Freezer

The Thermaster ZCDTD210 is a full-height supermarket combined freezer designed to maximise product visibility and drive impulse purchases on the retail floor. With a sleek, modern aesthetic and an illuminated top canopy for in-store advertising, this unit turns refrigerated storage into an active sales tool. It ships in two separate packages and is engineered for straightforward installation, making it a practical choice for supermarkets, convenience stores and specialty food retailers.

Combining a top freezer section with fan cooling and a bottom freezer section with static cooling, the ZCDTD210 handles a broad range of frozen product categories, including ice cream, in a single floor footprint. R290 natural refrigerant, auto-defrost, electronic digital temperature control, LED lighting, and energy-efficient glazing across both sections ensure consistent performance while keeping operating costs in check.

Key Benefits

• Illuminated top canopy and LED lighting draw customer attention to displayed products, actively supporting in-store sales and promotional activity.
• Compact, space-saving footprint allows the unit to fit into tighter retail floor layouts without sacrificing display capacity.
• Electronic digital temperature control and display gives staff precise, at-a-glance oversight of freezer conditions across both sections.
• Auto-defrost on both sections reduces routine maintenance demands, keeping the unit operating efficiently with minimal staff intervention.
• Triple-glazed, heat-film glass doors on the top section and Low-E tempered glass on the bottom section limit thermal transfer, supporting energy efficiency.
• Self-closing hinged doors on the top section and sliding doors on the bottom section help maintain stable temperatures during busy service periods.
• R290 natural refrigerant offers a lower environmental impact compared to conventional synthetic refrigerants.
• Adjustable feet allow the unit to be levelled on uneven retail floors, ensuring stable, safe placement.
• Optional manual defrost models are available on request, providing flexibility for operators with specific operational preferences.

Key Features

• Combined freezer unit with a top freezer section and a separate bottom freezer section in a single floor-standing cabinet
• R290 natural refrigerant used throughout
• Top section: fan cooling system, rated at 240V / 820W / 10A
• Bottom section: static cooling system with auto-defrost, rated at 240V / 500W / 10A
• Auto-defrost function on both sections; optional manual defrost models available on request
• Electronic digital temperature control and display for precise temperature management
• LED lighting throughout for enhanced product visibility
• Illuminated top canopy designed for in-store product advertising
• Top section: triple-glazed, self-closing glass doors with heat film and hinged self-closing mechanism
• Bottom section: Low-E tempered glass sliding doors
• Top section: stainless steel inner bottom for durability and ease of cleaning
• Bottom section: equipped with storage mesh or full baskets
• Adjustable feet for stable levelling on uneven surfaces
• Colorbond body construction
• Fixed installation with leg supports
• Five doors total across both sections
• Suitable for ice cream storage
• Delivered in two separate packages; installation and assembly not included
• Warranty: 2 years parts and labour plus 2 years parts only, for products registered within 14 days of invoice
• Dimensions: 2104mm wide x 850mm deep x 2110mm high; weight 417.25kg
• Packed dimensions: 2234mm wide x 994mm deep x 2360mm high

Specifications

• Width (mm): 2104
• Depth (mm): 850
• Height (mm): 2110
• Weight (kg): 417.25
• Packed Width (mm): 2234
• Packed Depth (mm): 994
• Packed Height (mm): 2360
• No. of Doors: 5
• Door Type: Sliding Doors
• Body Material: Colorbond
• Mobility: Fixed/Legs
• Defrost Type: Auto
• Cooling Type: Static
• Power Delivery: Top (240V, 820W/10A) Bottom (240V, 500W/10A)
• Power (kW): 240
• Warranty (months): 2 Years Parts and Labour + 2 Years Parts Only for Products Registered within 14 Days of Invoice
• Capacity (Litres): 559
